AVANT 735

AVANT 735

Avant 700 series offers strong and real multi-use loaders for jobs where high lift capacity and/or drive speed is needed, yet at the same time the machine shall be as compact as possible. The 700 series is the perfect tool for street cleaning and other property maintenance tasks on narrow streets and yards in the cities, lifting and handling bales, etc. on farms, handling paving stones, moving materials on construction sites, and in many other applications. Easy transportation with a car trailer and a high drive speed enable quick transfers between work sites.

High flow auxiliary hydraulics runs all Avant attachments which further increases the versatility of the machine.

A wide range of options increases operator comfort as well. 700 series can be fitted with all cab options, also with A/C, which ensures the perfect conditions for a full day’s work.

  • Cab options L/LX/DLX available, DLX also with A/C
  • Easy to transport with a car trailer
  • Optidrive™ drive circuit gives more power for the drive and hydraulic attachments

Avant’s ingenious articulated design where the driver sits in the front chassis and has a perfect view on the attachment and work area means low center of gravity of the machine, which is an important factor in the stability. Also the rigid articulation joint which doesn’t swing sideways increases stability in all situations and at the same time best possible traction can be achieved thanks to the advanced 4×4 system.

All Avant loaders are equipped with an open ROPS/FOPS certified cab as standard, and also the optional enclosed cabs (L, LX, DLX, GT) comply with the ROPS/FOPS standards.

While Avant loaders are made as compact as possible, the reach and lift height do not suffer from it.

Avant’s telescopic boom makes it possible to have a very compact machine with a great outreach and lift capacity. When the telescopic boom is retracted it is possible to lift heavier loads. With the boom fully extended, the reach and lift height are unparalleled.

In many cases, it is possible to load a trailer from one side thanks to the outreach of the telescopic boom and still have excellent all-round visibility.

Avant attachments have been designed to work as an equal partner on Avant loaders. The best machine-attachment combination and work efficiency can only be achieved when a good machine is fitted with attachments that are specifically designed for the machine. The dimensions, auxiliary hydraulics output and other features of Avant are in perfect balance with the attachments.

Avant loaders and attachments have been designed for year-round use which ensures that the machine is never sitting idle. The wide range of options available for the loaders – like four different cabs, extra work lights, the Opticontroltm attachment control system, etc. – together with technical solutions in the loaders make Avant as comfortable to use in the winter cold as it is on a sunny summer afternoon.

Avant’s hydraulic multi-connector system for coupling the attachment’s hydraulic hoses guarantees easy and effortless connecting and detaching in any situation with a single hand movement. It can be done with the engine running and/or pressure in the attachment, also in freezing ambient temperatures. The mechanism is leak-free and cannot be connected in the wrong way.

All articulated Avant loaders are equipped with a hydrostatic drive system. There is a hydraulic drive motor on each wheel. The drive circuit is equipped with valves with which traction can be controlled in different situations. In order to avoid tyre marks on soft and sensitive surfaces when turning, the system allows the wheels on the left and right sides of the loader to roll at different speeds. This also reduces tyre wear on hard surfaces.

The valves in the drive system work like a hydraulic 4×4 diff lock and equalize the oil flow between the left and right side hydraulic motors, improving traction on slippery and uneven surfaces.

AVANT 735

Outstanding handling capacity

Description

Avant 700 series offers strong and real multi-use loaders for jobs where high lift capacity and/or drive speed is needed, yet at the same time the machine shall be as compact as possible. The 700 series is the perfect tool for street cleaning and other property maintenance tasks on narrow streets and yards in the cities, lifting and handling bales, etc. on farms, handling paving stones, moving materials on construction sites, and in many other applications. Easy transportation with a car trailer and a high drive speed enable quick transfers between work sites.

High flow auxiliary hydraulics runs all Avant attachments which further increases the versatility of the machine.

A wide range of options increases operator comfort as well. 700 series can be fitted with all cab options, also with A/C, which ensures the perfect conditions for a full day’s work.

  • Cab options L/LX/DLX available, DLX also with A/C
  • Easy to transport with a car trailer
  • Optidrive™ drive circuit gives more power for the drive and hydraulic attachments

Reviews

There are no reviews yet.

Be the first to review “AVANT 735”

Your email address will not be published. Required fields are marked *

* Load is measured at 400 mm from the attachment coupling plate, including attachment weight (70 kg) and with counterweights.
Length 3060 mm
Width1295 mm
Height2060 mm
Weight 1800 kg
Standard wheels 320/60-12” HD TR
Transmission, drive Hydrostatic Avant OptidriveTM
Aux. hydraulics oil flow / pressure 50 l/min 240 bar
Hydraulic oil cooler Standard
Turning radius inside/outside 1240 / 2780 mm
Max. lifting height 3080 mm
Max. lifting capacity (hydr.) 2100 kg
Tipping load 1400 kg
Max. breakout force / 50 cm 1700 kg
Engine make and type Kubota V1505 Stage V, 4-cyl.
Engine output (ISO Gross) 19 kW (26 hp)
Maximum torque 93 Nm @ 1700 rpm
FuelDiesel
Wheel size ProfileWidth
27 x 8.50 - 15 tractor1030 mm
26 x 12.00 - 12 tractor or grass 1295 mm
320/60-12 HD tractor1295 mm
320/55-15 tractor or grass 1305 mm
400/50-15 tractor or grass
CAB TYPE 26 x 12.00-12 320 / 60-12 wheels 320 / 55-15 wheels
L Cab 2060 mm 2060 mm 2094 mm
LX Cab 2078 mm 2078 mm 2112 mm
DLX Cab 2105 mm 2105 mm 2139 mm
DLX with A/C on the roof 2241 mm 2241 mm 2275 mm
AVANT 735 - POWER FOR PROFESSIONALS
Engine Power - 26hp diesel 26hp diesel
Max Speed - 15.0 km/h 15.0 km/h
Lift Capacity - 1,400 kg 1,400 kg
Lift Height - 3.1 m 3.1 m
